PRODUCT SPOTLIGHT
-
DS-K2M0016A
. RS-485 communication with the master elevator controller
. Connectable with up to 16 relays to control the floor buttons in the elevator. Three types of
relays are supported: Button Relay, Call Elevator Relay and Auto Button Relay
. DIP switch settings for device address and relay types. Supports 3 relay types: Call Elevator,
Button, and Auto Button)
. Up to 8 distributed elevator controllers can be linked to the master elevator controller
(DS-K2210)
. Control the elevator via the relay
. Supports master elevator controller linkage, reporting the event to the system. -
DS-K2210
. Connectable with up to 2 Wiegand card readers or RS-485 card readers
. Connectable with up to 3 groups of distributed elevator controllers (DS-K2M0016A). Each
group is connectable with up to 8 distributed elevator controllers (DS-K2M0016A)
. Supports 3 types of relays: Button, Call Elevator and Auto Button
. Up to 128 floors’ permissions can be controlled
. Supports adding 20,000 normal cards and saving 50,000 events
. Supports uploading events, saving offline events
. Save the data when powering off
. Get the floor No. through permission management to control the corresponding relays
. Supports up to 256 schedule template. Each schedule template supports up to 1 week plan
and 4 holiday groups
. Supports 5 input terminals and 5 output terminals
-
DS-2DE4225IW-DE
- 1/2.8″ progressive scan CMOS
- Up to 1920 × 1080@30fps resolution
- Min. illumination:
- Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON) - 0 Lux with IR
- 25× optical zoom, 16× digital zoom
- WDR, HLC, BLC, 3D DNR, Defog, EIS, Regional Exposure, Regional Focus
- Up to 100 m IR distance
- 12 VDC & PoE+ (802.3 at, class4)
- Support H.265+/H.265 video compression
-
DS-2DF8425IX-AEL(W)
• 1/1.8” progessive scan CMOS sensor
• Up to 2592 × 1520 resolution
• 25X Optical Zoom
• Min. Illumination:
Color: 0.002 Lux @(F1.5, AGC ON)
B/W: 0.0002 Lux @(F1.5, AGC ON)
0 Lux with IR
• Smart Tracking
• Smart Detection
• 200m IR distance
• Optional wiper(-W)
• Hi-PoE / 24VAC power supply
• Support H.265+/H.265 video compression
• Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
• IP67, IK10
-
DS-2CD2643G1-IZ(S)
• 1/3″ Progressive Scan CMOS
• 2688 × 1520@30fps
• 2.8 to 12 mm varifocal lens
• Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
• H.265+, H.265, H.264+, H.264
• Three streams
• 120dB WDR
• 2 Behavior analyses, and face detection
• BLC/3D DNR/ROI/HLC
• IP67
• Built-in micro SD/SDHC/SDXC card slot, up to 128 GB
• 3-Axis adjustment
.png)
.png)
.png)
.png)
.png)
.png)
-
DS-2CD2783G1-IZ(S)
• 1/2.5″ Progressive Scan CMOS
• 3840 × 2160@15fps
• 2.8 to 12 mm varifocal lens
• Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
• H.265+, H.265, H.264+, H.264
• Three streams
• 120dB WDR
• 2 Behavior analyses, and face detection
• BLC/3D DNR/ROI/HLC
• IP67, IK10
• Built-in micro SD/SDHC/SDXC card slot, up to 128 GB
.png)
.png)
.png)
.png)
.png)
.png)
-
DS-2CD215RFWD-I
• Up to 5 megapixel high resolution
• Max. 2560 × 1920@20fps
• 2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional
• H.265, H.265+, H.264+, H.264
•120dB Wide Dynamic Range
• 3D Digital Noise Reduction
• DC12V & PoE (802.3af)
• IR range: up to 30 m
• Support on-board storage, up to 128 GB
• IP67, IK10
.png)
.png)
.png)
.png)
.png)
.png)
-
DS-2TD2137-7 (10 15 25 35)/VP
Smart Function (Thermal Imaging)
. Leading image processing technology: Adaptive AGC, DDE, 3D DNR, NETD < 40mk (@25°C,F#=1.0)
. Supporting HEOP, can build a wide range of cooperation system with integration partners
. Reliable temperature exception alarm function
. Advanced fire detection algorithm
Thermal Imaging Module Function
. 384*288 resolution, high sensitivity sensor, support contrast adjustment
. Shutter adjustment in various modes
. 3D DNR, 15 palettes of color adjustable, image detail enhancement
